◎ Applications:
155MbpsATM, 622MbpsATM, 1000Base-T, 10GBase-T
◎ Standards:
IEC61156-5 CAT7, EN 50288-4-1
◎ Product Construction Matrix:
| U/FTP | S/FTP | |
| Conductor | 22/23AWG Solid Plain Copper | 22/23AWG Solid Plain Copper |
| Insulation | PE | PE |
| Screen | Individual Aluminum Tape Screen | Individual Aluminum Tape Screen & Overall Copper Wire Braid |
| Drain Wire | 7/0.2mm | Nil |
| Outer Sheath | PE/PVC/LSF/LSZH/LSFROH | PE/PVC/LSF/LSZH/LSFROH |
Remark: PE- Polyethylene; PVC- Polyvinyl Chloride; LSF- Low Smoke & Fume; LSZH- Low Smoke Zero Halogen; LSFROH-Low Smoke Flame Retardant Zero Halogen (to IEC60332-3C); PVC can be classified as CMX, CM, CMR and CMP.
◎ Working Frequency:
1-600MHz
◎ Technical Parameters:
☆ Characteristic Impedance: 100±15Ω (1-250MHz); 100±22Ω (100-500Mhz)
☆ Nominal Velocity of Propagation (NVP): 79%
☆ Maximum Mutual Capacitance: 5.6nF/100m
☆ Maximum DC Resistance: 5.9Ω/100m (22AWG); 7.5Ω/100m (23AWG)
☆ Maximum Resistance Unbalance: 5%
☆ Maximum Propagation Delay Skew: 30ns/100m (1-125MHz)
☆ Maximum Propagation Delay: 536 ns/100m@100MHz
☆ Minimum Bending radius: 10 x Overall Diameter
☆ Voltage Rating: 60V rms
☆ Maximum Pulling load: 80N
☆ Working Temperature: -20℃ ~ +60℃
☆ Storage Temperature: -5℃ ~ +50℃
☆ Flame Retardancy: UL 1581 (CM Jacket), UL 1666 (CMR Jacket ) UL 910 (CMP Jacket); IEC 60332-1 (FRPVC & LSZH Jacket); IEC 60332-1and IEC 60332-3C (LSFROH Jacket)
◎ Product Categories :
| Construction | Conductor Diameter (mm) | Diameter Over Insulation (mm) | Pairs | Screen | Overall Diameter (mm) | Jacket |
| S/FTP | 0.57/0.64 | 1.02 | 4 | Individual Aluminum Tape Screen & Overall Copper Wire Braid | 8.4/9.1 | PVC/LSZH |
| S/FTP | 0.57/0.64 | 1.02 | 4 | Individual Aluminum Tape Screen & Overall Copper Wire Braid | 8.4/9.1 | LSFROH |
| U/FTP | 0.57/0.64 | 1.02 | 4 | Individual Aluminum Tape Screen | 7.5/8.5 | PVC/LSZH |
| U/FTP | 0.57/0.64 | 1.02 | 4 | Individual Aluminum Tape Screen | 7.5/8.5 | LSFROH |
◎ Product Highlights:
☆ Provide excellent bandwidth beyond 600 MHz.
☆ Support 10 Gigabit Ethernet application.
☆ Meet the strict flame retardancy and environmental requirements in Europe and US.
☆ Different jacket materials available for choice.
◎ Transmission Properties:
FREQ (MHz) |
NEXT(dB/100m) Min.Value/ Typical Value/ Standard Value |
IL (dB/100m) |
RL (dB) Min.Value/ Typical Value/ Standard Value |
ACR (dB/100m) Min.Value/ Typical Value/ Standard Value |
ELFEXT (dB/100m) Min.Value/ Typical Value/ Standard Value |
PSNEXT (dB/100m) Min.Value/ Typical Value/ Standard Value |
PSACR (dB/100m) Min.Value/ Typical Value/ Standard Value |
PSELFEXT (dB/100m) Min.Value/ Typical Value/ Standard Value |
| 1 | 90.0/100.0/80.0 | 2 | 20.0/23.0/20.0 | 88.0/98.0/78.0 | 85.0/90.0/80.0 | 87.0/97.0/77.0 | 85.0/95.0/75.0 | 82.0/87.0/77.0 |
| 4 | 90.0/100.0/80.0 | 3.6 | 23.0/26.0/23.0 | 86.4/96.0/76.4 | 85.0/90.0/80.0 | 87.0/97.0/77.0 | 83.4/93.0/73.4 | 82.0/87.0/77.0 |
| 10 | 90.0/100.0/80.0 | 5.7 | 25.0/28.0/25.0 | 84.3/94.0/74.3 | 79.0/90.0/74.0 | 87.0/97.0/77.0 | 81.3/91.0/71.3 | 76.0/87.0/71.0 |
| 16 | 90.0/100.0/80.0 | 7.2 | 25.0/28.0/25.0 | 83.3/92.0/72.8 | 74.9/90.0/69.9 | 87.0/97.0/77.0 | 80.3/89.0/69.8 | 71.9/87.0/66.9 |
| 20 | 90.0/100.0/80.0 | 8.1 | 25.0/28.0/25.0 | 82.5/91.0/71.9 | 73.0/90.0/68.0 | 87.0/97.0/77.0 | 79.5/88.0/68.9 | 70.0/87.0/65.0 |
| 31.25 | 90.0/100.0/80.0 | 10.1 | 23.6/26.0/23.6 | 80.0/90.0/69.9 | 69.1/90.0/64.1 | 87.0/97.0/77.0 | 77.0/87.0/66.9 | 66.1/87.0/61.1 |
| 62.5 | 90.0/100.0/75.5 | 14.5 | 21.5/24.0/21.5 | 76.0/85.0/61.0 | 63.1/85.0/58.1 | 80.0/97.0/72.5 | 73.0/82.0/58.0 | 60.1/82.0/55.1 |
| 100 | 90.0/100.0/72.4 | 18.5 | 20.1/23.0/20.1 | 72.5/75.0/53.9 | 59.0/80.0/54.0 | 87.0/97.0/69.4 | 69.5/72.0/50.9 | 56.0/77.0/51.0 |
| 200 | 90.0/100.0/67.9 | 26.8 | 18.0/23.0/18.0 | 65.0/70.0/41.1 | 53.0/75.0/78.0 | 87.0/97.0/64.9 | 62.0/67.0/38.1 | 50.0/72.0/45.0 |
| 250 | 95.0/90.0/66.5 | 30.2 | 17.3/23.0/17.3 | 50.0/58.0/36.3 | 51.0/70.0/46.0 | 92.0/87.0/63.5 | 47.0/55.0/33.3 | 48.0/67.0/43.0 |
| 300 | 95.0/90.0/65.3 | 33.3 | 17.3/23.0/17.3 | 59.0/55.0/32.0 | 49.5/66.0/44.5 | 92.0/87.0/63.3 | 56.0/52.0/29.0 | 46.5/63.0/41.5 |
| 600 | 80.0/90.0/60.8 | 48.9 | 17.3/20.0/17.3 | 32.0/50.0/11.9 | 43.4/60.0/38.4 | 77.0/87.0/57.8 | 29.0/47.0/8.9 | 40.4/57.0/35.4 |
◎ Ordering Information :
| Model | Product Description |
| AD-BC-CAT7STP4PCM22 | U/FTP Cat7 22AWG 4Pairs, CM Grade (Non-Plenum) |
| AD-BC-CAT7STP4PCM23 | U/FTP Cat7 23AWG 4Pairs, CM Grade (Non-Plenum) |
| AD-BC-CAT7SFTP4PCM22 | S/FTP Cat7 22AWG 4Pairs, CM Grade (Non-Plenum) |
| AD-BC-CAT7SFTP4PCM23 | S/FTP Cat7 23AWG 4Pairs, CM Grade (Non-Plenum) |
| AD-BC-CAT7STP4PLH22 | U/FTP Cat7 22AWG 4Pairs, LSZH Grade (IEC60332-1) |
| AD-BC-CAT7STP4PLH23 | U/FTP Cat7 23AWG 4Pairs, LSZH Grade (IEC60332-1) |
| AD-BC-CAT7SFTP4PLH22 | S/FTP Cat7 22AWG 4Pairs, LSZH Grade (IEC60332-1) |
| AD-BC-CAT7SFTP4PLH23 | S/FTP Cat7 23AWG 4Pairs, LSZH Grade (IEC60332-1) |
| AD-BC-CAT7STP4PFRLH22 | U/FTP Cat7 22AWG 4Pairs, LSFROH Grade (IEC60332-1 & IEC60332-3C) |
| AD-BC-CAT7STP4PFRLH23 | U/FTP Cat7 23AWG 4Pairs, LSFROH Grade (IEC60332-1 & IEC60332-3C) |
| AD-BC-CAT7SFTP4PFRLH22 | S/FTP Cat7 22AWG 4Pairs, LSFROH Grade (IEC60332-1 & IEC60332-3C) |
| AD-BC-CAT7SFTP4PFRLH23 | S/FTP Cat7 23AWG 4Pairs, LSFROH Grade (IEC60332-1 & IEC60332-3C) |
Cat7 u/ftp
Cat7 f/ftp
